PALLET TRUCK»Semi Electric Scissor Pallet Truck

Semi Electric Scissor Pallet Truck

INR 105,000

540MM
680MM
540MM
Model Number : VI-ESLP-1500-1150-540-85X
HSN Code : 84279000
Stock: In-Stock

Main Specs : Rapid lifting, 1000 & 1500 kg capacity, one piece lifting cylinder, integrated charger
680MM
Model Number : VI-ESLP-1500-1150-680-85X
HSN Code : 84279000
Stock: In-Stock

Main Specs : Rapid lifting, 1000 & 1500 kg capacity, one piece lifting cylinder, integrated charger

Equipment Details


VIMAL semi electric scissor pallet truck can be used for handling or working platforms. It’s compact body design, fast lift pump action, can save time and improve labour efficiency. Widely used in factories, workshops, warehouses, supermarkets etc. The unique design of the hydraulic valve achieves automatic deceleration control. The deceleration rate remains stable regardless of heavy load or empty load, which prevents damage to the cargo. When the forks are lowered to a height of 420 mm, the front support wheel and the adjustable stabilizer will automatically extend to the ground to ensure optimal stability and braking performance.

TECHNICAL SPECIFICATIONS




 VI-ESLP-1000-1150-540-85X
VI-ESLP-1000-1150-680-85X
VI-ESLP-1500-1150-540-85X
VI-ESLP-1500-1150-680-85X
Capacitykg1000100015001500
Lifting heightmm800800800800
Fork lengthmm1150115011501150
Fork widthmm540580540680
Min/Max fork heightmm85/80085/80085/80085/800
BatteryV/Ah12/ 6012/ 6012/ 6012/ 60
Charging voltageV220220220220
Power outputKW0.80.80.80.8
Weightkg169169174174
